Electron quick start

This is not a full tutorial but just the commands I need to run inorder to get electron installed in a new project

Oran C

Dec 27, 2021 • 4 min read

This is not a full tutorial but just the commands I need to run inorder to get electron installed in a new project

Your package.json file should look something like this:

{
"name": "my-electron-app",
.....
"main": "main.js",
"scripts": {
    "start": "electron ."
}
......
"license": "MIT"
}

Create the following files...

index.html

<!--index.html-->

<!DOCTYPE html>
<html>
  <head>
    <meta charset="UTF-8">
    <!-- https://developer.mozilla.org/en-US/docs/Web/HTTP/CSP -->
    <meta http-equiv="Content-Security-Policy" content="default-src 'self'; script-src 'self'">
    <meta http-equiv="X-Content-Security-Policy" content="default-src 'self'; script-src 'self'">
    <title>Hello World!</title>
  </head>
  <body>
    <h1>Hello World!</h1>
    We are using Node.js <span id="node-version"></span>,
    Chromium <span id="chrome-version"></span>,
    and Electron <span id="electron-version"></span>.

    <!-- You can also require other files to run in this process -->
    <script src="./renderer.js"></script>
  </body>
</html>

main.js

// main.js

// Modules to control application life and create native browser window
const { app, BrowserWindow } = require('electron')
const path = require('path')

function createWindow () {
  // Create the browser window.
  const mainWindow = new BrowserWindow({
    width: 800,
    height: 600,
    webPreferences: {
      preload: path.join(__dirname, 'preload.js')
    }
  })

  // and load the index.html of the app.
  mainWindow.loadFile('index.html')

  // Open the DevTools.
  // mainWindow.webContents.openDevTools()
}

// This method will be called when Electron has finished
// initialization and is ready to create browser windows.
// Some APIs can only be used after this event occurs.
app.whenReady().then(() => {
  createWindow()

  app.on('activate', function () {
    // On macOS it's common to re-create a window in the app when the
    // dock icon is clicked and there are no other windows open.
    if (BrowserWindow.getAllWindows().length === 0) createWindow()
  })
})

// Quit when all windows are closed, except on macOS. There, it's common
// for applications and their menu bar to stay active until the user quits
// explicitly with Cmd + Q.
app.on('window-all-closed', function () {
  if (process.platform !== 'darwin') app.quit()
})

// In this file you can include the rest of your app's specific main process
// code. You can also put them in separate files and require them here.

preload.js

// preload.js

// All of the Node.js APIs are available in the preload process.
// It has the same sandbox as a Chrome extension.
window.addEventListener('DOMContentLoaded', () => {
  const replaceText = (selector, text) => {
    const element = document.getElementById(selector)
    if (element) element.innerText = text
  }

  for (const dependency of ['chrome', 'node', 'electron']) {
    replaceText(`${dependency}-version`, process.versions[dependency])
  }
})

quick start comands

development at this stage

npm install --save-dev electron
npm start

Package the app executable

npm install --save-dev @electron-forge/cli

npx electron-forge import

npm run make

where the resulting exe is located! `./out/<name-of-app>-win32-x64/<name-of-app>.exe`

open that shit!

Sucess! 🎉🎊🎉

Bonus advanced github actions

name: Build/release

on: push

jobs:
  release:
    runs-on: ${{ matrix.os }}

    strategy:
      matrix:
        os: [macos-latest, ubuntu-latest, windows-latest]

    steps:
      - name: Check out Git repository
        uses: actions/checkout@v1

      - name: Install Node.js, NPM and Yarn
        uses: actions/setup-node@v1
        with:
          node-version: 10

      - name: Build/release Electron app
        uses: samuelmeuli/action-electron-builder@v1
        with:
          # GitHub token, automatically provided to the action
          # (No need to define this secret in the repo settings)
          github_token: ${{ secrets.github_token }}

          # If the commit is tagged with a version (e.g. "v1.0.0"),
          # release the app after building
          release: ${{ startsWith(github.ref, 'refs/tags/v') }}

how to test locally

I have a blog post about this for more info

For the lazy:

windows: this is important ADMIN WINDOW!

Set-ExecutionPolicy Bypass -Scope Process -Force; [System.Net.ServicePointManager]::SecurityProtocol = [System.Net.ServicePointManager]::SecurityProtocol -bor 3072; iex ((New-Object System.Net.WebClient).DownloadString('https://community.chocolatey.org/install.ps1'))
choco install act-cli
act -l
act

Author

by oran collins
github.com/wisehackermonkey

20211227
