Electron quick start
This is not a full tutorial but just the commands I need to run inorder to get electron installed in a new project
This is not a full tutorial but just the commands I need to run inorder to get electron installed in a new project
Your package.json
file should look something like this:
{
"name": "my-electron-app",
.....
"main": "main.js",
"scripts": {
"start": "electron ."
}
......
"license": "MIT"
}
Create the following files...
index.html
<!--index.html-->
<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8">
<!-- https://developer.mozilla.org/en-US/docs/Web/HTTP/CSP -->
<meta http-equiv="Content-Security-Policy" content="default-src 'self'; script-src 'self'">
<meta http-equiv="X-Content-Security-Policy" content="default-src 'self'; script-src 'self'">
<title>Hello World!</title>
</head>
<body>
<h1>Hello World!</h1>
We are using Node.js <span id="node-version"></span>,
Chromium <span id="chrome-version"></span>,
and Electron <span id="electron-version"></span>.
<!-- You can also require other files to run in this process -->
<script src="./renderer.js"></script>
</body>
</html>
main.js
// main.js
// Modules to control application life and create native browser window
const { app, BrowserWindow } = require('electron')
const path = require('path')
function createWindow () {
// Create the browser window.
const mainWindow = new BrowserWindow({
width: 800,
height: 600,
webPreferences: {
preload: path.join(__dirname, 'preload.js')
}
})
// and load the index.html of the app.
mainWindow.loadFile('index.html')
// Open the DevTools.
// mainWindow.webContents.openDevTools()
}
// This method will be called when Electron has finished
// initialization and is ready to create browser windows.
// Some APIs can only be used after this event occurs.
app.whenReady().then(() => {
createWindow()
app.on('activate', function () {
// On macOS it's common to re-create a window in the app when the
// dock icon is clicked and there are no other windows open.
if (BrowserWindow.getAllWindows().length === 0) createWindow()
})
})
// Quit when all windows are closed, except on macOS. There, it's common
// for applications and their menu bar to stay active until the user quits
// explicitly with Cmd + Q.
app.on('window-all-closed', function () {
if (process.platform !== 'darwin') app.quit()
})
// In this file you can include the rest of your app's specific main process
// code. You can also put them in separate files and require them here.
preload.js
// preload.js
// All of the Node.js APIs are available in the preload process.
// It has the same sandbox as a Chrome extension.
window.addEventListener('DOMContentLoaded', () => {
const replaceText = (selector, text) => {
const element = document.getElementById(selector)
if (element) element.innerText = text
}
for (const dependency of ['chrome', 'node', 'electron']) {
replaceText(`${dependency}-version`, process.versions[dependency])
}
})
quick start comands
development at this stage
npm install --save-dev electron
npm start
Package the app executable
npm install --save-dev @electron-forge/cli
npx electron-forge import
npm run make
where the resulting exe is located! ./out/<name-of-app>-win32-x64/<name-of-app>.exe
open that shit!
Sucess! 🎉🎊🎉
Bonus advanced github actions
name: Build/release
on: push
jobs:
release:
runs-on: ${{ matrix.os }}
strategy:
matrix:
os: [macos-latest, ubuntu-latest, windows-latest]
steps:
- name: Check out Git repository
uses: actions/checkout@v1
- name: Install Node.js, NPM and Yarn
uses: actions/setup-node@v1
with:
node-version: 10
- name: Build/release Electron app
uses: samuelmeuli/action-electron-builder@v1
with:
# GitHub token, automatically provided to the action
# (No need to define this secret in the repo settings)
github_token: ${{ secrets.github_token }}
# If the commit is tagged with a version (e.g. "v1.0.0"),
# release the app after building
release: ${{ startsWith(github.ref, 'refs/tags/v') }}
how to test locally
I have a blog post about this for more info
For the lazy:
windows: this is important ADMIN WINDOW!
Set-ExecutionPolicy Bypass -Scope Process -Force; [System.Net.ServicePointManager]::SecurityProtocol = [System.Net.ServicePointManager]::SecurityProtocol -bor 3072; iex ((New-Object System.Net.WebClient).DownloadString('https://community.chocolatey.org/install.ps1'))
choco install act-cli
act -l
act
Author
by oran collins
github.com/wisehackermonkey
20211227
